US Type Grade 30 Proof Coil Chain

• Carbon Steel.

• Minimum Ultimate load is 4 times the Working Load Limit.

• Proof Tested at 2 times the Working Load Limit with certification.

• Finish – Self colored and galvanized.

Products Introduction

Caution:

Do Not Use for Overhead Lifting.

DO NOT EXCEED THE WORKING LOAD LIMIT.

Specifications

Nominal Chain Size		Working Load Limit (MAX.)		Proof Test (Min.)		Breaking Force (Min.)		Inside Length (Max.)		Inside Width (Max.)		WT kg/100ft


INCH	MM	LBS	KG	LBS	KN	LBS	KN	INCH	MM	INCH	MM
1/8”	4	400	180	800	3.6	1600	7.2	0.94	23.9	0.25	6.4	8.51
3/16”	5.5	800	365	1600	7.2	3200	14.4	0.98	24.8	0.3	7.7	17.34
1/4”	7	1300	580	2600	11.6	5200	23.2	1.24	31.5	0.38	9.8	28.12
5/16”	8	1900	860	3800	16.9	7600	33.8	1.29	32.8	0.44	11.2	42.36
3/8”	10	2650	1200	5300	23.6	10600	47.2	1.38	35	0.55	14	63.03
7/16”	11.9	3700	1680	7400	32.9	14800	65.8	1.64	41.6	0.65	16.6	89.26
1/2”	13	4500	2030	9000	40	18000	80	1.79	45.5	0.72	18.2	106.53
5/8”	16	6900	3130	13800	61.3	27600	122.6	2.2	56	0.79	20	159.01
3/4”	20	10600	4800	21200	94.3	42400	188.6	2.76	70	0.98	25	248.46
7/8”	22	12800	5810	25600	114.1	51200	228.2	3.03	77	1.08	27.5	300.63
1”	26	17900	8140	35800	159.1	71600	318.2	3.58	90.9	1.25	31.7	418.8
