Stainless Steel U Bolt With 2 Plates & Nuts
U-Bolts, also known as Tube Bolts and U Clamp Bolts, these are used for a wide variety of fastening applications, since their u-shaped design makes them very versatile. Our U-bolts are made from stainless steel and have welded base plates to minimize potential corrosion and offer superior sealing.
Products Introduction
Product Features:
- 304 or 316 Stainless Steel.
- Highly Polished Finish.
- Fitted with 2 Plates & Nuts.
- 4mm 5mm 6mm 8mm 10mm and 12mm diameters available.
Specifications
| ITEM NO | D1 | L1 | L | D | A | WT |
|---|---|---|---|---|---|---|
| mm | mm | mm | mm | mm | KGS | |
| PF0851-A/B0430 | 4 | 30 | 62 | 5 | 30 | 0.035 |
| PF0851-A/B0548 | 5 | 48 | 78 | 6 | 36 | 0.048 |
| PF0851-A/B06421 | 6 | 42 | 80 | 8 | 36 | 0.072 |
| PF0851-A/B06422 | 6 | 42 | 90 | 8 | 36 | 0.08 |
| PF0851-A/B0840 | 8 | 40 | 80 | 10 | 35 | 0.114 |
| PF0851-A/B0852 | 8 | 52 | 100 | 10 | 45 | 0.133 |
| PF0851-A/B10351 | 10 | 35 | 90 | 12 | 50 | 0.199 |
| PF0851-A/B10352 | 10 | 35 | 110 | 12 | 50 | 0.219 |
| PF0851-A/B1080 | 10 | 80 | 135 | 12 | 50 | 0.243 |
| PF0851-A/B1265 | 12 | 65 | 130 | 14 | 60 | 0.34 |
| PF0851-A/B1285 | 12 | 85 | 150 | 14 | 60 | 0.38 |
