EN818-7 GRADE T ( 80 ) HOIST CHAIN TYPE T
- SHORT LINK CHAIN FOR LIFTING PURPOSES
- CONFORMS TO EUROPEAN STANDARD EN818-7
- PRODUCED FROM THE HIGHEST QUALITY ALLOY STEEL
- EMBOSSED WITH “T8”
- QUENCHED AND TEMPERED, PROOF TESTED
- IN ACCORDANCE WITH 4-TO-1 DESIGN FACTOR
- BLACK ELECTROPHORESIS FINISH OR ZINC PLATED FINISH
WARNING: DO NOT EXCEED THE WORKING LOAD LIMITS !
Products Introduction
Specifications
| NOMINAL SIZE | PITCH | EXTERNAL WIDTH | INTERNAL WIDTH | WORKING LOAD LIMIT | PROOF LOAD | MIN. BREAKING LOAD | MIN. BEND DEFLECTION | WEIGHT |
|---|---|---|---|---|---|---|---|---|
| D | L | B | b | |||||
| mm | mm | mm | mm | T | kN | kN | mm | KG/M |
| 4 | 12 | 13.2 | 5.2 | 0.5 | 12.6 | 20.1 | 3.2 | 0.349 |
| 5 | 15 | 16.5 | 6.5 | 0.8 | 19.6 | 31.4 | 4 | 0.545 |
| 6 | 18 | 19.8 | 7.8 | 1.1 | 28.3 | 45.2 | 4.8 | 0.785 |
| 7 | 21 | 23.1 | 9.1 | 1.5 | 38.5 | 61.6 | 5.6 | 1.069 |
| 8 | 24 | 26.4 | 10.4 | 2 | 50.3 | 80.4 | 6.4 | 1.396 |
| 9 | 27 | 29.7 | 11.7 | 2.5 | 63.6 | 102 | 7.2 | 1.849 |
| 10 | 30 | 33 | 13 | 3.2 | 78.5 | 126 | 8 | 2.181 |
| 12 | 36 | 39.6 | 15.6 | 4.5 | 113 | 181 | 9.6 | 3.251 |
| 13 | 39 | 43 | 17 | 5.3 | 133 | 212 | 10 | 3.689 |
| 16 | 48 | 55.5 | 23.5 | 8 | 201 | 322 | 13 | 5.571 |
| 18 | 54 | 61 | 25 | 10 | 254 | 407 | 14 | 7.154 |
| 20 | 60 | 68 | 28 | 12.5 | 314 | 503 | 16 | 8.641 |
| 22 | 66 | 73.5 | 29.5 | 15 | 380 | 608 | 18 | 10.391 |
